Trident Therra 2
SKU: TT-GW-0007-MB-01-21-01
Price on request
On/off ground-source and water-to-water heat pump for heating, cooling and domestic hot water. Single-phase, with soft starter, R32 refrigerant, optional passive cooling, Wi-Fi module, cloud-based remote monitoring and BMS communication.
Key features
Questions about this product?
Get in touch with us.
Specifications
The Trident Therra 2 is a compact ground-source / water-to-water heat pump that offers an efficient heating and cooling solution for buildings with lower heat demand. Thanks to the ground or water heat source, the unit delivers stable output and high efficiency all year round, regardless of the outdoor ambient temperature.
An ideal solution for smaller properties
With 7 kW rated heating capacity and 6 kW rated cooling capacity, the Trident Therra 2 is ideal for detached houses, smaller residential properties or low-energy buildings. The system works well with modern low-temperature heating systems and with fan coil cooling.
Energy-efficient and quiet operation
High COP and EER values mean low electricity consumption, while the reliable scroll on/off compressor guarantees dependable operation over the long term. The compact size and low noise level also allow installation in mechanically more sensitive surroundings.
Simple installation, compact design
The Trident Therra 2 provides heating, active cooling and domestic hot water in a single compact unit. It is also suitable for passive cooling, which considerably simplifies system design and installation. The solution fits equally well into the building services of new builds and renovation projects.
Who is it for?
The Trident Therra 2 is an ideal choice for:
-
smaller detached houses,
-
holiday homes,
-
low-energy residential buildings,
where a suitable well-water or ground heat source is available. It works well with both underfloor heating and fan coil systems.
Basic data
| Model | Trident Therra 2 |
|---|---|
| Heat pump type | ground-source / water-to-water |
Key features
| Rated heating capacity (W15/W40) | 7 kW |
|---|---|
| Rated power consumption (heating) | 1.6 kW |
| COP | 5.6 |
| Rated cooling capacity (W15/W7) | 6 kW |
| Rated power consumption (cooling) | 1.2 kW |
| EER | 4.8 |
Heat outputs
| Heating - rated conditions | |
|---|---|
| Heating capacity (W15/W40) | 7 kW |
| Electrical power input | 1.6 kW |
| COP | 5.6 |
| Cooling - rated conditions | |
| Cooling capacity (W15/W7) | 6 kW |
| Electrical power input | 1.2 kW |
| EER | 4.8 |
Performance data
| Refrigerant | R32 |
|---|
Electrical data
| Power supply | 230 V / single-phase / 50 Hz |
|---|---|
| Max. current draw | 13 A |
Hydraulic data - primary circuit (heat source)
| Heat exchanger type | Plate heat exchanger |
|---|---|
| Water flow rate | 1.3 m³/h |
| Pressure drop | 10 kPa |
| Pipe connection | G3/4" |
Hydraulic data - secondary circuit (heating/cooling)
| Heat exchanger type | Plate heat exchanger |
|---|---|
| Water flow rate | 1.2 m³/h |
| Pressure drop | 10 kPa |
| Pipe connection | G3/4" |
Compressor data
| Compressor brand | Panasonic |
|---|---|
| Compressor type | Scroll, on/off |
Operating limits
| Max. flow temperature | 60 °C |
|---|
Weight data
| Weight | 65 kg |
|---|
Dimensions
| Width | 530 mm |
|---|---|
| Depth | 390 mm |
| Height | 670 mm |
Noise level
| Noise level | 43 dB(A) |
|---|
